Tools and Equipment - Transmission Jacks

PRODUCT DETAILS

The Norco 72025 is a 1-1/2 ton wide-chassis open-front truck transmission jack. The open front and wide chassis let the saddle and transmission sit lower for easier removal.

FEATURES

• Fully adjustable saddle with angle brackets for positioning the transmission.
• Four 4 in. risers for transmissions with offset transfer cases.
• Two heavy-duty ratchet tie-downs secure the load to the saddle.
• Overload safety system limits loads to the ASME/PASE standard.
• 360-degree rotating handle works in any position.
• Chrome-plated ram helps keep rust out of the hydraulic system.
• Four full-swivel ball bearing 4 in. casters for easy positioning.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

The Norco 72060 is a 500 lb. capacity DPF handler and drive shaft installation tool. A wide, open-front chassis lets the saddle sit low and spreads the load for stability, and the bean bag saddle removes the need for separate DPF adapters.

FEATURES

• Open front and wide chassis let the saddle and transmission sit lower for easier removal.
• Universal bean bag saddle removes the need for separate DPF transmission adapters.
• Universal, fully adjustable saddle with adjustable corner brackets and a safety chain.
• Saddle tilt knobs are easy to reach.
• Overload safeguard keeps the jack within the ASME/PASE load-limiting standard.
• Pump handle rotates 360 degrees and works in any position.
• Chrome-plated ram helps keep rust out of the hydraulic system.
• Four ball-bearing swivel casters.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

The Norco 72000E is a 1-1/2 ton hydraulic transmission jack, made in the USA, with a wide chassis and open front that gives extra room around the saddle and transmission.

FEATURES

• Wide chassis with open front provides a wider opening for the saddle and transmission.
• Heavy-duty chain with a chain tensioner secures the load to the saddle.
• Full 360-degree rotating handle operates in any position.
• Flash-chromed ram inhibits rust from entering the hydraulic system.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

The Norco 72050E is a 1/2 ton hydraulic transmission jack with a fully adjustable universal saddle and swivel casters for positioning under a vehicle.

FEATURES

• Fully adjustable universal saddle with adjustable corner brackets and safety chain.
• Full 360-degree rotating pump handle operates in any position.
• Four full-swivel ball bearing caster wheels for easy positioning.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

The Norco 72450B is a 1/2 ton telescopic air/hydraulic transmission jack with the FASTJACK feature and a foot pump for hands-free operation. It is designed for lifting transmissions in under-hoist applications.

FEATURES

• Air/hydraulic foot pump provides hands-free operation and easy lifting.
• Metered pump valve provides safe lowering of the load.
• Wide base with four swivel ball bearing caster wheels, 4 in. diameter polyurethane.
• Polyurethane wheels help protect tile and epoxy floors.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

Half-ton telescopic under hoist transmission jack with a single-pump design, suited to shops that service a variety of vehicles.

FEATURES

• Fully adjustable universal saddle with hand-adjustable corner brackets and safety chain.
• Safety overload system prevents use beyond the load-limiting standard.
• Foot-operated pump and lowering pedals leave both hands free to position the saddle.
• Two-stage flash-chromed rams inhibit rust from entering the hydraulic system.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

Half-ton telescopic under hoist transmission jack with a double-pump design, built for removing, installing, and transporting transmissions and transfer cases on passenger cars, vans, and light trucks raised on a lift.

FEATURES

• Double-pump design rises twice as fast as the 72500E with no load or loads up to 400 pounds.
• Matches the 72500E rising speed for loads between 400 and 1,000 pounds.
• Fully adjustable universal saddle with hand-adjustable corner brackets and safety chain.
• Safety overload system prevents use beyond the load-limiting standard.
• Foot-operated pump and lowering pedals leave both hands free to position the saddle.
• Two-stage flash-chromed rams inhibit rust from entering the hydraulic system.
• Four 4-inch swivel ball bearing casters with polyurethane wheels protect tile and epoxy floors.

SPECS

PRODUCT DIMENSIONS

PRODUCT DETAILS

The Norco 72701A is a 1-ton under-hoist air/hydraulic truck transmission jack. A foot-operated air/hydraulic pump and a 2 in. single-stage ram give stable, hands-free lifting.

FEATURES

• Air/hydraulic foot pump provides hands-free operation and easy lifting.
• Metered pump valve provides safe lowering of the load.
• Heavy-duty chain with a chain tensioner secures the load to the saddle.
• 2 in. diameter flash-chromed single-stage ram adds stability throughout the lift range.

SPECS

PRODUCT DIMENSIONS
