Tools and Equipment - Lift Tables

or browse the results below.

Page 1 of 1 (Showing results 1 - 5 of 5)
1.) BX50 - Item No.
Manufacturer: Bishamon

Mobile Lift Table


Product image of Bishamon BX50 on HCRCnow.com.
Price: N/A Request Quote
2.) 72674 - Item No.
Manufacturer: Norco

1,250 Lbs. Capacity Powertrain Lift / Table


INTENDED USE:

The powertrain lift/table not only handles transmissions and fuel tanks, but also engines and transaxles, rear ends and leaf springs. Also serves as a work table where the components can be lowered to a stable and secure work height for repair.

FEATURES:
  • Fingertip control for both pressure and release operations provides finer control of raising or lowering loads.
  • Safety overload system in the air/hydraulic pump prevents jack from being used beyond the load-limiting standard.
  • The pump can be removed from its holder and placed closer to the lift saddle, leaving hands free to accurately position the load.
  • Fully adjustable saddle with two ratchet tie downs secure the load to the saddle.
  • Four easy rolling caster wheels (locking rear caster wheels) provides stability and easy maneuvering in its lowered position.
  • The wheels, made from a phenolic resin, offer high impact resistance and are non-marking for protection of tile and epoxy floors.
  • The optional model 72508 Fuel Tank Saddle Adapter can be quickly and easily installed.
DIMENSIONS:
Low Lift Height 25.5"
High Lift Height 65"
Length 57"
Width 42.75"
Height 44.5"
Table Size 20.25" x 32.25"
Shipping Weight 410 lbs.




Product image of Norco 72674 on HCRCnow.com.

Download PDF
Click - Download PDF of Drawing

This is our estimated shipping charge. If the actual charge is higher we will contact you before shipment.

 Price: $2,951.27 Request Quote
3.) 72675 - Item No.
Manufacturer: Norco

Power Train Lift / Table 1,250 lbs


Product image of Norco 72675 on HCRCnow.com.

Download PDF
Click - Download PDF of Drawing 		Price: Discontinued This product has been discontinued.
4.) 72850 - Item No.
Manufacturer: Norco


Product image of Norco 72850 on HCRCnow.com.

Download PDF
Click - Download PDF of Drawing

This is our estimated shipping charge. If the actual charge is higher we will contact you before shipment.

 Price: Discontinued This product has been discontinued.
5.) 72855 - Item No.
Manufacturer: Norco

2,500 Lbs. Capacity EV Battery Lift / Table


INTENDED USE:

For removing, installing, and transporting large electric vehicle batteries. It will also serve as a work table where components can be lowered to a convenient work height for repairs.

FEATURES:
  • An airhydraulic foot pumo includes a metered valve for safe lowering of the load.
  • Safety overload system in the air/hydraulic pump prevents jack from being used beyond the load-limiting standard
  • Five foot extension hose with quick disconnect fittings stores in the lift base.  The foot pump can be removed from its holder and hydraulic hose quickly and easily extended by 5' using the extension hose.  This provides hands free operation of the pump anywhere around the lift's perimeter.
  • Scissors lift design provides easy 360 degree access to any component.
  • Two heav duty ratchet tie-downs are included to safely secure the load on the lift table.
  • 10' base clearance height
  • Table top heiht from 35-1/2" to 77"
  • Four 8" diameter swivel caster wheels for easy maneuverability
  • Rear wheels can be locked to prevent the lift from rolling.
DIMENSIONS:
Low Lift Height 35.5"
High Lift Height 77"
Length 65"
Width 36.25"
Height 40.625"
Table Size 36.25” x 42.5”
Shipping Weight 570 lbs.




Product image of Norco 72855 on HCRCnow.com.

Download PDF
Click - Download PDF of Drawing 		Price: $5,733.49 Request Quote
Page 1 of 1 (Showing results 1 - 5 of 5)
